The Complete CCTV Pipe Inspection Procedure

Table of Content [Hide]

    CCTV pipe inspections have become the gold standard for assessing the condition of pipelines efficiently and accurately. Using a pipe CCTV camera system, professionals can identify blockages, cracks, corrosion, and other defects without invasive digging or disruption. In this guide, we'll walk through the complete CCTV pipe inspection procedure and explain how Easy Sight's advanced technology supports seamless and reliable inspections.


    Understanding CCTV Pipe Inspections


    CCTV pipe inspections involve inserting a specialized camera into the pipeline to capture real-time video footage of the interior condition. The pipe CCTV camera is typically mounted on a crawler or a floating platform to navigate through pipes of various sizes and materials. The live video feed allows operators to assess the structural integrity of the pipeline, detect issues such as leaks or obstructions, and determine necessary maintenance or repairs.


    Using a CCTV camera for pipe inspection eliminates guesswork by providing clear, high-resolution visuals. This non-destructive technique helps municipalities, industrial facilities, and construction teams monitor infrastructure without excavation or downtime, saving both time and money.


    Step-by-Step CCTV Pipe Inspection Procedure


    Preparation and Setup


    Before the inspection, the team reviews the pipeline layout and selects the appropriate CCTV pipe inspection equipment based on pipe diameter and conditions. Easy Sight offers flexible solutions controlled via personal laptops or dedicated controllers, providing operators with full command over the camera system. The pipe CCTV camera is connected either through a wired or wireless interface depending on site constraints.


    Deployment of the Camera System


    The pipe CCTV camera is carefully inserted into the pipeline. For smaller or partially filled pipes, manual drag methods may be used, while larger or complex systems often deploy a crawler or floating platform. Easy Sight's advanced crawler systems ensure smooth navigation through bends, joints, and rough pipe surfaces.


    Inspection and Data Collection


    Once inside the pipe, the camera system sends live video back to the control unit. Operators adjust lighting, pan, tilt, and zoom functions to capture detailed views of the pipe walls. Any signs of damage such as cracks, root intrusion, corrosion, or sediment buildup are recorded. The video feed can be stored for later analysis and reporting.


    Data Analysis and Reporting


    After the inspection, experts analyze the footage to evaluate pipe conditions and identify potential problems. Using Easy Sight's user-friendly software, detailed inspection reports with timestamped images and video clips can be generated, streamlining decision-making and maintenance planning.


    Advantages of Using Easy Sight's CCTV Pipe Inspection Technology


    Easy Sight has engineered its pipe CCTV cameras and inspection systems to maximize inspection accuracy, efficiency, and ease of use. Key benefits include:


    • High-Resolution Imaging: Clear, HD video ensures operators don't miss critical defects.


    • Versatile Control: Compatible with laptops and specialized controllers, operators can tailor the interface to field conditions.


    • Flexible Deployment: Systems can be used with crawlers, manual drag, or floating methods, adapting to different pipeline environments.


    • Reliable Data Storage: Real-time video is saved securely for post-inspection analysis and reporting.


    • Cost-Effective Maintenance: Early detection reduces the need for costly emergency repairs.


    Recommended Product: Easy Sight X7 CCTV & Sonar Pipe Inspection System


    For advanced inspections, Easy Sight's X7 CCTV & Sonar Pipe Inspection system integrates both sonar imaging and CCTV video technologies. This floating detection system uses a sonar head and a rotating CCTV lens placed on the water surface inside full or half-filled pipes. The combination enables accurate detection in submerged conditions where traditional cameras alone might struggle.



    The X7 system can be controlled via a personal laptop or specialized controller. Its ability to glide or float through pipelines offers unparalleled flexibility, making it perfect for water utilities, municipal sewer inspections, and industrial pipelines where water flow is a factor.


    CCTV pipe inspections are essential for maintaining safe, functional pipeline infrastructure. Easy Sight's innovative pipe CCTV cameras and inspection systems, like the X7, deliver precise diagnostics that save time and reduce maintenance costs. Investing in these advanced technologies ensures your pipelines stay in optimal condition for years to come.


    Our smart inspection devices support customized services. To receive a tailored quotation, feel free to contact our sales team for professional assistance.
